The 4223AA Series™ internal gear API pump is the ideal solution for your upstream, midstream, and downstream liquids due to its reduced risk of leakage, reduced risk of VOC emissions, and reduced risk of corrosion failure. It can handle flows up to 500 GPM (114 m³/h).
Features & Benefits
- Static o-ring sealed joints provided improved sealing vs. flat gaskets
- Additional metal thickness around tapped holes at least half the bolt diameter
- Non-Destructive evaluation of castings to ensure quality
to 500 GPM
to 114 m³/h
28 to 35,000 SSU
1 to 7,700 cSt
to 200 PSI
to 14 Bar
-20 to +550 °F
-30 to +290 °C
|Model||Standard Port Size||Nominal Pump Rating GPM||Nominal Pump Rating m³/h||Maximum RPM||Maximum Pressure PSI||Maximum Pressure BAR|
Diesel (#3 Fuel Oil)
Diesel is distilled from petroleum and is typically used in heavy equipment as fuel. While it is thin diesel is somewhat lubricating. It is typically handled in a bulk transfer application or on back-up generator skids.
This is a very generic term for unrefined oils typically being recovered from the ground. Some crude oil may contain particulates from the oil well or recovery method. They are considered to be flammable liquids. Crude oils are later refined and used for everything from making plastics to gasoline.
- Ductile iron
- Hardened, DLC coated parts for robust, long-lasting field performance
- Capacities to 210 GPM
- Cast iron
- Abrasive resistant sealing options
- Hardened materials standard
- Capacities to 180 GPM
Clean asphalt contains no fillers and is an oil based liquid. It is primarily used in paving roads, waterproofing liquids, and paints. Typically they are handled at elevated temperatures to reduce the viscosity of the asphalt. The pump needs a source of heat like jacketing or electric heat to prevent the product from solidifying in the pump.
- Cast iron
- Leak prevention with O-Pro® Cartridge seal
- Capacities to 280 GPM
- Jacketed for steam/oil heating prior to pump startup
Emulsions are asphalt suspended in a mixture with water or other liquids. This is done to ease the application of the asphalt. Uses would be crack filling, coating roadways, or waterproofing. These emulsions are shear sensitive and must be handled with care.
- Cast iron
- Jacketed for steam/oil heating prior to startup
- Mechanical seal options
- Capacities to 500 GPM
Filled asphalts contain particulate used in the liquids’ end applications. Examples of this would be roofing materials and hot mix plants. Typically they are handled at elevated temperatures to reduce the viscosity of the asphalt mixture. The pump needs a source of heat like jacketing or electric heat to prevent the product from solidifying in the pump.
