The SG-X Series™ motor speed pump is UL listed for fuel oil, providing the best solution for this liquid. It can handle flows up to 11 GPM (42 LPM).
Features & Benefits
- Needle bearings provide high pressure capabilities, sleeve bearing options available
- Close-coupled motor mount or foot bracket options to match space or motor requirements
- Capacities up to 11 GPM
Capacity
to 11 GPM
to 42 LPM
Viscosity
28 to 1,000,000 SSU
1 to 250,000 cSt
Pressure
to 500 PSI
to 34 Bar
Temperature
-40 to +450 °F
-40 to +230 °C
Options
Porting
Opposite (180°)
NPT
Drives
D Direct-Mounted Drive
M Motor Mounted Drive
B Bracket Mounted Drive
Mounting
Foot Mount
Motor Mount
Sealing
Lip Seal
Component Mechanical Seal
Mag Drive
Specifications
Standard Size | Standard Port Inches | Nominal Capacity At 1750 RPM (GPM) | Nominal Capacity At 1750 RPM (LPM) | Continuous Pressure* PSI | Continuous Pressure* BAR |
---|---|---|---|---|---|
SG-0518 / 40518 / 80518 | 0.50 | 0.7 | 2.6 | 500 | 34 |
SG-0525 / 40525 / 80525 | 0.5 | 1 | 3.8 | 500 | 34 |
SG-0535 / 40335 / 80535 | 0.50 | 1.4 | 5.3 | 500 | 34 |
SG-0550 / 40550 / 80550 | 0.50 | 2 | 7.6 | 500 | 34 |
SG-0570 / 40570 / 80570 | 0.5 | 2.8 | 10.6 | 500 | 34 |
SG-0510 / 40510 / 80510 | 0.5 | 4 | 15.1 | 500 | 34 |
SG-0514 / 40514 / 80514 | 0.75 | 5.6 | 21.2 | 500 | 34 |
SG-0519 / 40519 / 80519 | 0.75 | 7.6 | 28.8 | 200 | 14 |
SG-0528 / 40528 / 80528 | 0.75 | 11.2 | 42.4 | 100 | 7 |
