The Revolution® Series is a positive displacement pump with circumferential piston rotors. This is the ideal solution for pharmaceutical, personal care, foods, and more due to its cleanability, superior performance, and ease of maintenance. It can handle flows up to 399 GPM (91 m³/h).
Features & Benefits
Cleanability
- Efficient CIP (Clean In Place) ability is standard for all Revolution pumps
- Self draining pump head from innovative cusps & cusp reliefs
- Innovative seal design with no dead zones & a dynamic leak path
- No dead zones on front cover
Ease of Maintenance
- Fast, front loading seal changes while pump is still in line
- Front access shimming for setting rotor clearance significantly reduces maintenance time
- Convenient preventive maintenance parts kits available
Performance
- Improved volumetric efficiency in low & high viscosity applications
- Up to 15% better flow performance than competitors’ CIP configuration
- Gentle handling of solids & shear sensitive products
- Long-life durability from heavy duty shafts, bearings & helical gears
- Less overhung load
Capacity
to 399GPM
to 91 m³/h
Viscosity
0 to 2,000,000 SSU
0 to 440,000 cSt
Pressure
to 450 PSI
to 31 Bar
Temperature
0 to 300 °F
0 to 150 °C
Options
Porting
Drives
Mounting
Sealing
Specifications
Model | Standard Port Size | Nominal Pump Rating (GPM) | Nominal Pump Rating (m3/h) | Maximum RPM | Maximum Pressure PSI | Maximum Pressure BAR |
---|---|---|---|---|---|---|
R0150X | 1.5" | 11 | 2.6 | 800 | 305 | 21 |
R0180P | 1.5" | 23 | 5.3 | 800 | 203 | 14 |
R0200X | 1.5" | 34 | 8 | 800 | 305 | 21 |
R0300X | 1.5" | 48 | 11 | 800 | 247 | 17 |
R0400X | 2" | 62 | 14 | 800 | 203 | 14 |
R0450X | 2" | 67 | 15 | 600 | 450 | 31 |
R0600P | 2.5" | 92 | 21 | 600 | 305 | 21 |
R0800X | 2.5" | 122 | 28 | 600 | 247 | 17 |
R1300X | 3" | 159 | 36 | 600 | 203 | 14 |
R1800X | 3" | 231 | 53 | 600 | 450 | 31 |
R1830X | 3" | 231 | 53 | 600 | 450 | 31 |
R2200X | 4" | 313 | 71 | 600 | 305 | 21 |
R2230X | 4" | 313 | 71 | 600 | 305 | 21 |
R2600P | 4" | 399 | 91 | 600 | 203 | 14 |
R2630P | 4" | 399 | 91 | 600 | 203 | 14 |
Videos

Pharmaceuticals
Pharmaceuticals are substances used in the diagnosis, treatment and/or prevention of diseases in humans and animals. Can also be referred to as drugs and medications.

Cream (from Dairy)
Cream is a dairy product that is typically the fatty part of milk that rises to the top if allowed to stand. It is used in butter production and other food applications.

Acetone
Acetone is an organic compound and an important solvent used in the paints and varnishes, in resins and as a degreasing agent.

Blood Products
Therapeutic products derived from human blood including whole blood, plasma and other blood components for transfusion and medical treatment.

Butter
A pale yellow edible fat made from the churning of dairy cream. Used as a spread or as an ingredient in food preparation and cooking.
-
DRAWINGS
R0450X/31 - 2" DIN 11851 Top Shaft Drive PDF
STEP
R2200X - 4" ASA/ANSI Class 150 Top Shaft Drive PDF
STEP
R0400X - 2" ASA/ANSI Class 150 Vertical PDF
R0300X - 1.5" Tri-Clamp (3A) Top Shaft Drive PDF
STEP
R0180P - 1.5" ASA/ANSI Class 150 Bottom Shaft Drive PDF
STEP
R0300X - 1.5" DIN 11851 Top Shaft Drive PDF
STEP
R0300X - 1.5" Tri-Clamp Vertical PDF
STEP
R1300X - 3" Tri-Clamp Vertical PDF
STEP
R0150X - 1.5" DIN 11851 Drop Shaft Drive PDF
STEP
R1300X - 3" DIN 11851 Top Shaft Drive PDF
STEP
R0300X - 1.5" SMS Bottom Shaft Drive PDF
STEP
R0180P - 1.5" SMS Vertical with Jacketing PDF
STEP
R0300X - 1.5" SMS Vertical with Jacketing PDF
STEP
R0450X - 2" Tri-Clamp (3A) Bottom Shaft Drive PDF
STEP
R2200X - 4" Tri-Clamp Bottom Shaft Drive PDF
STEP
R0450X - 2" DIN 11851 Vertical with Top/Bottom Shaft Drive PDF
STEP
R0200X - 1.5" ASA/ANSI Class 150 Bottom Shaft Drive PDF
STEP
R2600P - 4" Tri-Clamp (3A) Bottom Shaft Drive PDF
STEP
R1300X - 3" Tri-Clamp (3A) Top Shaft Drive PDF
STEP
R2600P - 4" ASA/ANSI Class 150 Bottom Shaft Drive PDF
STEP
R0450X - 2" ASA/ANSI Class 150 Vertical with Jacketing PDF
STEP
R1800X - 3" ASA/ANSI Class 150 Vertical with Jacketing PDF
STEP
R0150X - 1.5" Tri-Clamp Vertical PDF
STEP
R2200X - 4" SMS Bottom Shaft Drive PDF
STEP
R0400X - 2" DIN 11851 Vertical PDF
STEP
R0450X - 2" Tri-Clamp Top Shaft Drive with Jacketing PDF
STEP
R0180P - 1.5" DIN 11851 Top Shaft Drive PDF
STEP
R0200X - 1.5" DIN 11851 Bottom Shaft Drive PDF
STEP
R1800X - 3" Tri-Clamp Bottom Shaft Drive PDF
STEP
R1800X - 3" SMS Top Shaft Drive PDF
STEP
R0800X - 2.5" SMS Top Shaft Drive PDF
STEP
R2200X - 4" Tri-Clamp Top Shaft Drive with Jacketing PDF
STEP
R0150X - 1.5" ASA/ANSI Class 150 Top Shaft Drive PDF
STEP
R0600P - 2.5" Tri-Clamp Top Shaft Drive PDF
STEP
R0400X - 2" Tri-Clamp Top Shaft Drive PDF
STEP
R0400X - 2" SMS Bottom Shaft Drive PDF
STEP
R0600P - 2.5 DIN 11851 Bottom Shaft Drive PDF
STEP
R0200X - 1.5" Tri-Clamp Bottom Shaft Drive PDF
STEP
R1300X - 3" SMS Top Shaft Drive PDF
STEP
R0180P - 1.5" Tri-Clamp Top Shaft Drive with Flushing PDF
STEP
R0300X - 1.5" ASA Class 150 Top Shaft Drive PDF
STEP
R0600P - 2.5" DIN 11851 Vertical PDF
STEP
R1300X - 3" ASA/ANSI Class 150 Bottom Shaft Drive PDF
STEP
R1800X - 3" DIN 11851 Bottom Shaft Drive with Flushing PDF
STEP
R2600P - 6" ASA/ANSI Class 150 Bottom Shaft Drive PDF
STEP
R1800X - 3" ASA/ANSI Class 150 Top Shaft Drive PDF
STEP
R2200X - 4" SMS Vertical PDF
STEP
R1300X - 3" SMS Vertical PDF
STEP
R0800X - 2.5" SMS Vertical PDF
STEP
