This product has been replaced by a new innovation. Click here to navigate to our recommended replacement OBSOLETE REPLACEMENT Model Manual Catalog Section Model Manual Catalog Section H123 TSM 151.1 Sec 151 H123C HL123 TSM 151.1 Sec 151 HL123C Service Manual | 2300 Catalog Section | 2301 Non-Jacketed K123 TSM 151.1 Sec 151 K123C Service Manual | 2300 Catalog Section | 2301 Non-Jacketed KK123 TSM 151.1 Sec 151 KK123C Service Manual | 2300 Catalog Section | 2301 Non-Jacketed LQ123 TSM 151.1 Sec 151 L123C M123 TSM 151.1 Sec 151 QS123C Service Manual | 2300 Catalog Section | 2301 Non-Jacketed DOWNLOADS Performance Videos Liquids Downloads Capacity to 420 GPM to 95 m3/h Viscosity 28 to 2,000,000 SSU 0.1 to 440,000 cSt Pressure 200 PSI 14 BAR Temperature -20 to +800°F -29 to +427°C Options Porting Flanged (ASME / ANSI) Drives R Offset Gear Reducer Drive D Direct-Mounted Drive Mounting Foot Mount Sealing Packing Specifications Model Standard Port Size Nominal Pump Rating (GPM) Nominal Pump Rating (m3/h) Maximum RPM Maximum Pressure PSI Maximum Pressure BAR H123 1.5" 15 3 1800 400 28 HL123 1.5" 30 7 1800 400 28 K123 2" 60 14 640 400 28 KK123 2" 80 18 640 400 28 LQ123 2.5" 135 31 640 400 28 LL123 3" 140 32 520 400 28 LS123 3" 200 45 640 400 28 Q123 4" 300 68 520 400 28 M123 4" 420 95 420 400 28 Select model for more detailed information: H123 , HL123 , K123 , KK123 , LQ123 , LL123 , LS123 , Q123 , M123 TSM / Catalog / Flyers / Brochures TSM 151.1 Download Technical Service Manuals TSM 151.2 Download Technical Service Manuals Sec 151 Download Catalog Sections
