Rugged and reliable pumping solutions for industrial applications from paint to asphalt.
Go to Industrial Solutions
Durable and reliable solutions utilizing external gear technology for rebuild ability and top performance.
Go to Energy Solutions
From biopharmaceuticals to peanut butter, our hygienic segment offers gentle handling solutions.
Go to Hygienic Solutions
8 a 400 GPM
1.8 a 91 m³/h
100 zu 2,000,000 SSU
20 zu 440,000 cSt
a 200 PSI
a 14 Bar
0 zu +350 °F
-15 zu +175 °C
| Modello | Dimensioni standard dell'attacco | Capacità nominale (GPM) | Capacità nominale (m³/h) | RPM massimo | Pressione massima PSI | Pressione massima BAR |
|---|---|---|---|---|---|---|
| H1124A | 1.5 | 8 | 1.8 | 1000 | 200 | 14 |
| HL1124A | 1.5 | 18 | 4 | 1000 | 200 | 14 |
| K1124A | 2 | 80 | 18 | 780 | 200 | 14 |
| KK1124A | 2 | 100 | 23 | 780 | 200 | 14 |
| LQ1124A | 2 | 135 | 31 | 640 | 200 | 14 |
| LQ1124A | 2.5 | 135 | 31 | 640 | 200 | 14 |
| LL1124A | 3 | 140 | 32 | 520 | 200 | 14 |
| LS1124A | 3 | 200 | 45 | 640 | 200 | 14 |
| Q1124A | 4 | 275 | 62 | 470 | 200 | 14 |
| QS1124A | 6 | 400 | 91 | 470 | 200 | 14 |
