zu 500 GPM
zu 114 m³/h
28 zu 250,000 SSU
1 zu 55,000 cSt
zu 200 PSI
zu 14 Bar
-60 zu +450 °F
-51 zu +230 °C
| Modell | Standard-Anschlussgröße | Pumpen-Nennleistung (GPM) | Nennleistung der Pumpe (m3/h) | Maximale Drehzahl | Maximaler Druck PSI | Maximaler Druck BAR |
|---|---|---|---|---|---|---|
| H4224B | 1.5 | 15 | 3.4 | 1750 | 200 | 14 |
| HL4224B | 1.5 | 30 | 7 | 1750 | 200 | 14 |
| K4224B | 2 | 75 | 18 | 780 | 200 | 14 |
| KK4224B | 2 | 100 | 23 | 780 | 200 | 14 |
| L4224B | 2 | 135 | 31 | 640 | 200 | 14 |
| LQ4224B | 2.5 | 135 | 31 | 640 | 200 | 14 |
| LL4224B | 3 | 140 | 32 | 520 | 200 | 14 |
| LS4224B | 3 | 200 | 45 | 640 | 200 | 14 |
| Q4224B | 4 | 300 | 68 | 520 | 200 | 14 |
| QS4224B | 6 | 500 | 114 | 520 | 200 | 14 |
| H-HL with Relief Valve - 1.5" NPT RH |
|
|
| K-KK with Plain Head - 2" NPT RH/LH |
|
|
| K-KK with Plain Head - 3" Class 125 ANSI RH |
|
|
| K-KK with Relief Valve - 2" NPT RH |
|
|
| L with Jacketed Relief Valve - 3" Class 125 ANSI RH |
|
|
| L with Plain Head - 2" NPT RH/LH |
|
|
| L with Relief Valve - 2" NPT RH/LH |
|
|
| L with Relief Valve - 3" Class 125 ANSI RH |
|
|
| LL with Jacketed Relief Valve - 3" Class 125 ANSI RH/LH |
|
|
| LL with Plain Head - 3" Class 125 ANSI RH/LH |
|
|
| LL with Relief Valve - 3" Class 125 ANSI RH/LH |
|
|
| LQ with Plain Head - 2.5" Class 125 ANSI RH/LH |
|
|
| LQ with Relief Valve - 2.5" Class 125 ANSI RH/LH |
|
|
| LS with Plain Head - 3" Class 125 ANSI RH/LH |
|
|
| LS with Relief Valve - 3" Class 125 ANSI RH/LH |
|
|
| Q with Jacketed Head - 4" Class 125 ANSI RH/LH |
|
|
| Q with Jacketed Relief Valve - 4" Class 125 ANSI RH |
|
|
| Q with Relief Valve - 4" Class 125 ANSI RH/LH |
|
|
| QS with Jacketed Head - 6" Class 125 ANSI Opposite |
|
|
| QS with Jacketed Relief Valve - 6" Class 125 ANSI Opposite |
|
|
| QS with Relief Valve - 6" Class 125 ANSI Opposite |
|
|
