Die Innenzahnradpumpe der Serie 1227A™ mit O-Pro®-Dichtungstechnologie ist aufgrund ihrer zuverlässigen Abdichtung und einfachen Wartung die perfekte Lösung für Melasse, Zuckerslurries, Maissirup und vieles mehr. Sie kann Durchflussmengen von 6 bis 320 GPM (1,4 bis 73 m³/h) bewältigen.
Merkmale & Vorteile
- Konstruktion aus Edelstahl 316 für Kompatibilität mit Prozessflüssigkeiten
- O-Pro® Guard bietet eine robuste Dichtungslösung für viele Märkte
- Das wiederaufbaubare Design von O-Pro® Guard sorgt für minimale Ausfallzeiten und niedrige Kosten
- Integrierte Heizmantel-Kammern in Halterung und Kopf ermöglichen es den Pumpen, eine konstante Temperatur und einen gleichmäßigen Produktfluss aufrechtzuerhalten
Kapazität
6 zu 320 GPM
1.4 zu 73 m³/h
Viskosität
28 zu 75,000 SSU
1 zu 17,000 cSt
Druck
zu 150 PSI
zu 10 Bar
Temperatur
-15 zu +350 °F
-25 zu +175 °C
Optionen
Anschlüsse
Rechtwinklig (90°) (drehbares Gehäuse), H-Q
Inline (180°) (drehbares Gehäuse), QS
Geflanscht (ASME / ANSI)
Antriebe
R Versetztes Untersetzungsgetriebe
P Separat gekauftes Untersetzungsgetriebe
V Drive | Keilriemenantrieb
Montage
Fubmontage
Abdichtung
O-Pro® Guard-Dichtung
Spezifikationen
| Modell | Standard-Anschlussgröße | Pumpen-Nennleistung (GPM) | Nennleistung der Pumpe (m3/h) | Maximale Drehzahl | Maximaler Druck PSI | Maximaler Druck BAR |
|---|---|---|---|---|---|---|
| H1227A | 1.5 | 6 | 1.4 | 760 | 150 | 10 |
| HL1227A | 1.5 | 13 | 3 | 760 | 150 | 10 |
| K1227A | 2 | 50 | 11 | 520 | 150 | 10 |
| KK1227A | 2 | 65 | 15 | 520 | 150 | 10 |
| LQ1227A | 2.5 | 100 | 23 | 520 | 150 | 10 |
| LL1227A | 3 | 135 | 31 | 520 | 150 | 10 |
| LS1227A | 3 | 160 | 36 | 520 | 150 | 10 |
| Q1227A | 4 | 200 | 45 | 350 | 150 | 10 |
| QS1227A | 6 | 320 | 73 | 350 | 150 | 10 |
Photos
Videos
TSM / Catalog / Flyers / Brochures
-
REPAIR RESOURCES
Quick Tip #01 - Setting End Clearance on a Viking Pump Universal Seal Pump O-ring Replacement: O-Pro® Guard Seal How to Use a Thrust Bearing Locknut Tool Viking Pump Universal Seal Series with Stuffing Box Component Seals Repair Kit Installation Quick Tip #02 - Install Mechanical Seal into Stuffing Box in Viking Pump Universal Seal Pump Viking Pump: Converting to the O-Pro® Guard Seal
-
DRAWINGS
H-HL with Jacketed Head - 1.5" Class 150 ANSI RH/LH PDF
STEP
K-KK with Plain Head - 2" Class 150 ANSI RH/LH PDF
L with Jacketed Relief Valve - 3" Class 125 ANSI RH PDF
STEP
LL with Jacketed Relief Valve - 3" Class 125 ANSI RH PDF
STEP
LL with Plain Head - 3" Class 125 ANSI RH/LH PDF
STEP
LL with Relief Valve - 3" Class 125 ANSI RH/LH PDF
STEP
LQ with Jacketed Relief Valve - 2.5" Class 125 ANSI RH PDF
STEP
LQ with Plain Head - 2.5" Class 125 ANSI RH/LH PDF
STEP
LQ with Relief Valve - 2.5" Class 125 ANSI RH/LH PDF
STEP
LS with Plain Head - 3" Class 125 ANSI RH/LH PDF
STEP
LS with Relief Valve - 3" Class 125 ANSI RH/LH PDF
STEP
Q with Jacketed Head - 4" Class 125 ANSI RH/LH PDF
STEP
Q with Jacketed Relief Valve - 4" Class 125 ANSI RH PDF
STEP
Q with Relief Valve - 4" Class 125 ANSI RH/LH PDF
STEP
QS with Jacketed Head - 6" Class 125 ANSI Opposite PDF
STEP
QS with Jacketed Relief Valve - 6" Class 125 ANSI Opposite PDF
STEP
QS with Relief Valve - 6" Class 125 ANSI Opposite PDF
STEP
